LED Illuminated Marine Oil Pressure Gauge 052536

12/24 volt oil pressure marine gauge, 90 degrees sweep dial. LED illumination in either white or yellow, plastic cased and with stainless steel bezel. Screw collar type fitting. Supplied with threaded temp sensor.  Fitted with 600mm of cable.

Technical Data

Gauge Type Panel mount oil pressure marine gauge

Voltage 12/24 volt DC

Scale 90 deg sweep – 0-10 Bar

Illumination Choice of white or yellow

Panel cut out 52mm dia

Max panel depth 25mm

Protection IP67 (from the front)

Body Material Plastic

Bezel Material Stainless steel

Sensor type Screw thread pressure sensor

Grounding Insulated return

Screw Thread 1/8 inch x 27NPT

Resistance 0-160Ohms
